Salter Brecknell DS-1000 Drum Scale DS-1000 $636.00 Salter Brecknell SBI-140 Floor Indicator Stand, add $79.95 Specifications Chart

Optional Indicator Stand Not Included

Portable Drum Weigher Scale featuring a powder coated rugged steel platform with a smooth top surface and built in ramps. Includes an SBI 100 indicator with 6 digit, red LED, easy to ready display.

Construction– Powder coated rugged steel with smooth top plate surface and two handles and wheels to easily relocate. Adjustable foot pads to work effectively on uneven floors. Built-in ramp ends for recessed floors

Easy Assembly No installation costs or parts that require maintenance. Just place the scale on a hard surface and level by adjusting the foot pads. Connect the power and youre ready to go.

Low Profile– 63.5 mm (2.5") high

Specifications

Model	DS-1000
	$636.00
Capacity x Readability	1,000 lb x 0.5 lb
	500 kg x 0.2 kg
Platform size	31.5" L x 31.5" W x 1.8" H
Indicator	9.75" W x 5.25" L x 6.5" H
Display	6 digit 20 mm (0.8") LED display
Power	120/220VAC @ 60/50 HZ, 12 VDC, 500mA, UL, CE & BS approved external power adapter
Rechargeable Internal Battery	6V4AH lead acid battery up to 30 hours of continuous use between charges
Battery Life	Approximately 30 hours
Overload Capacity	Capable of withstanding 150% capacity of weight without damaging the scale.
Operating Temp	5º C to 35º C (41º F to 95º F)
Platform Construction	Powder coated rugged steel with smooth top plate surface with four 1000 ohm loadcells
Serial Port	RS-232: Full Duplex, standard 9 pin straight pass through interface connector (interface cable included)
Keyboard	On/Off/Zero, Tare, Units, Hold/Print
Unit	lb, kg
Tare	100% subtractive
Unit Weight	106 lb (48 kg)
Shipping Weight	185 lb (84 kg)
Optional Stainless Steel Guard Rail	Product Code: AWT05-504386 Guard Rail Dimensions: 860 mm x 700 mm (33.85" x 27.6")
Optional Indicator Stand:	Product Code: 816965002061 Stand Height: 965 mm (38") Stand Base: 292 mm x 292 mm x 19 mm (13.8" x 13.8" x 0.75")
Warranty	one year
