| Model |
R2-500 |
R2-1000 |
| Price |
| Scale with CI-100A |
$845.75
|
$975.00
|
| Capacity x Readability |
500 x 0.2 lb |
1000 x 0.5 lb |
| Platform Size |
31.5 x 31.5 x 1.8
800 x 800 x 46 |
| Cable Length |
10 ft - J-Box to Indicator |
| Overall Dimensions |
Inch: 41.3 (W) x 41.3 (D) - mm: 1050 (W) x 1050 (D) x 68 (H) |
| Product Weight |
105.8 lbs / 48 kg |
| Operating Environment |
-10ºC ~ 40ºC / -14ºF ~ 104ºF |
CAS CI-2001 Series Indicator
The CI-2001 Seres Indicator with RS-232. Use in a variety of applications - floor scales, livestock scales, platform scales, pallet scales, and much more. With its bright red display, the CI-2001 Series Indicator is easy to read. Legal for trade.
- Compact & Simple Indicator
- Power : AC Adapter
- Single Pass Automatic Span Calibration
- RFI/EMI Screened / Watch - Dog Function
- Wall/Panel Mounting Type
- kg/lb Switchable
- Gross/Net/Tare
- IP 65/NEMA4X Indicator enclosure(CI-2001AS/BS)
- NTEP Approval number :98-103
| Model |
CI-2001A |
CI-2001B |
CI-2001AS |
CI-2001BS |
| Input Sensitivity |
2 V/D(H- 44, OIML)
0.5 V/D(Non H - 44, OIML) |
| Zero Adjust Range |
0.05~5mV |
| Load Cell Excitation |
DC 5V, Up to 4 350 Load Cells |
| A/D Conversion Speed |
10 times/sec |
| A/D Display Resolution |
5,000dd(H- 44, OIML)
30,000dd(Non H - 44, OIML) |
| A/D Internal Resolution |
Approximately 200,000 Counts |
| Weight Display |
6 Digit LED
(H=0.55 ) |
6 Digit LCD
(H=1) |
6 Digit LED
(H=1) |
6 Digit LCD
(H=1) |
| Operating Temperature |
-10 C~+40 C |
| Dimensions(inch) |
7.32(W) 2.28(D) 3.34(H) |
7.87(W) 5.11(D) 2.08(H) |
| Product Weight(lb/kg) |
Approximately 1.10/0.5 |
Approximately 3.30/1.5 |
CAS CI-100A Indicator
The CI-100A is a simple, yet versatile indicator with NTEP and Measurement Canada certifications suitable for legal for trade use. Functionality includes:Weight ? Count ? Percentage ? Accumulation ? Hold ? Checkweighing ? Animal Weighing Capabilities
With a display resolution up to 1/100,000, visibility is insured by a blue backlit 1" high LCD display.
Standard features include a full
duplex RS232 serial interface, USB interface, multiple
communication protocols, time & date, and various
selectable units of measurement including lb, kg, g, oz,
lb:oz, pieces (non-commercial only), and percent.
| Model |
CI-100A |
| Construction |
Aluminum Alloy Housing with Desk/Wall Mount Bracket |
| Display |
6-digit, 7-segment , 1" (25mm) LCD with 16 annunciators and blue backlight |
| Display Designators |
Stable, Zero, Net, Total, Unit, Percent, Counting, Hold, HI/OK/LO, Battery |
| Units |
Kg, lb, lb:oz, g, oz, pcs (Non-Commercial only), % |
| Accuracy |
<= 0.01% Full Scale |
| Function Keys |
Setup/Hold, Print/Func, Acc/Total, Unit/Data, Tare/Preset, ON/OFF/Zero |
| Vibration Filter |
Four (4) Adjustable Filter Settings - Reduce Vibration/Assist in Configuring Indicator Speed & Stability |
| Calibration |
Linearity calibration, GEO calibration, or Input Calibration |
| Load Cell Capability |
4 @ 350 ohm |
| Communication |
One Full Duplex RS232 Interface, One USB Interface |
| Excitation Voltage |
5V DC |
| Operating Environment |
-10ordm;C ~ 40ordm;C / -14ordm;F ~ 104ordm;F |
| Dimensions |
6.4" (L) x 3.5" (W) x 1.2" (H)
162mm(L) x 80mm(W) x 29mm(H) |
| Power Source |
6VDC 500mA Adapter (Included) or 4 x AA batteries |
| Product Weight |
2.7 lb / 1.3 kg |
| Warranty |
2 Years |
| Approvals |
NTEP: COC# 16-103
Measurement Canada: AM-6044
CE, WEEE Directive, UL/CUL |
