Mark-10 R50 Universal Torque Sensors	Authorized Dealer
Measure bi-directional torque for a wide variety of applications. Contains a chuck for samples up to 1/2" in diameter, depending on capacity. The sensor can be used as a hand held device, or mounted to a torque test stand. Capacities available from 10 ozin to 100 lbin
Force Measurement >> Mark-10

View Specifications Cart View Test Stands Specifications Chart

Mark-10 R50 Universal Torque Sensors FREE UPS Ground Shipping (within the 48 continental US States) Model: Select MR50-10Z $969.00 MR50-20Z $969.00 MR50-50Z $969.00 MR50-12 $893.00 MR50-50 $893.00 MR50-100 $893.00

Series R50 smart sensors measure bi-directional torque for a wide variety of applications across virtually all industries. Contain a Jacobs chuck for up to 0.5 in [12.7 mm] diameter samples, bits, or fixtures. The sensors can be used as hand held devices, or mounted to a test stand. Capacities available from 10 ozFin to 100 lbFin [7 to 1150 Ncm]. Compatible with Mark-10 model 5i and 3i indicators (sold separately) through unique Plug & TestTM technology.

• Compatible with the 5i and 3i digital indicators
• Unique Plug & TestTM connector holds all calibration and configuration data
• Rugged aluminum housing
• NIST-traceable certificate of calibration included
• Accuracy: ± 0.35% of full scale ±1 digit + indicatorWeight: From 1.4 lbs (0.6 kg)
• Warranty: 3 years

Model		MR50-10Z	MR50-20Z	MR50-50Z	MR50-12	MR50-50	MR50-100
		$969.00	$969.00	$969.00	$893.00	$893.00	$893.00
Capacity x Resolution With Model 3i	ozFin	10 x 0.01	20 x 0.02	50 x 0.05	-	-	-
	lbFin	-	-	-	12 x 0.01	50 x 0.05	100 x 0.1
	kgFmm	7 x 0.005	14 x 0.01	36 x 0.05	140 x 0.1	580 x 0.5	1150 x 1
	Ncm	7 x 0.005	14 x 0.01	36 x 0.05	135 x 0.1	570 x 0.5	1150 x 1
Capacity x Resolution With Model 5i	ozFin	10 x 0.006	20 x 0.01	50 x 0.02	-	-	-
	lbFi	-	-	-	12 x 0.005	50 x 0.02	100 x 0.05
	lbFft	-	-	-	1 x 0.0005	4 x 0.002	8 x 0.005
	gFcm	700 x 0.5	1400 x 1	3600 x 2	-	-	-
	kgFmm	7 x 0.005	14 x 0.01	36 x 0.02	140 x 0.1	580 x 0.5	1150 x 0.5
	Nmm	70 x 0.05	140 x 0.1	350 x 0.2	-	-	-
	Ncm	7 x 0.005	14 x 0.01	35 x 0.02	135 x 0.1	570 x 0.5	1150 x 0.5
	Nm	-	-	-	1.35 x 0.001	5.7 x 0.005	11.5 x 0.005
