Mark-10 R51 Universal Torque Sensors	Authorized Dealer
A great solution for general bi-directional torque testing applications requiring different sample sizes. Three interchangeable chuck capacities and bit holder are available. The R51 has superb overload protection and is available in capacities from 10 ozin to 100 lbin.
Force Measurement >> Mark-10

Image R50 with optional G1017 View Specifications Cart Interchangeable chucks (order separately) Specifications Chart Due to the increased possibility of overload resulting from a higher weight attachment used with a lower capacity torque sensor, the G1016-2 and G1016-3 attachments are recommended for use only with an MR51-12 or higher capacity model

Mark-10 R51 Universal Torque Sensors FREE UPS Ground Shipping (within the 48 continental US States) Model: Select MR51-10Z $907.25 MR51-20Z $907.25 MR51-50Z $907.25 MR51-12 $836.00 MR51-50 $836.00 MR51-100 $836.00    Mark-10 G1016-1 STH or R51 Torque Sensor Attachments, 0.028 to 0.25 in dia, add $156.75 Mark-10 G1016-2 STH or R51Torque Sensor Attachments, 0.052 to 0.375 in dia, add $161.50 Mark-10 G1016-3 STH or R51 Torque Sensor Attachments, 0.078 to 0.5 in dia, add $166.25 Mark-10 G1017 STH or R51 Bit Holder, 1/4 in hex, add $166.25

Series R51 smart sensors measure bi-directional torque for numerous applications across virtually all industries. Interchangeable Jacobs chucks and bit holder add flexibility for a variety of applications. The sensors can be used as hand held devices or mounted to a test stand. Superb overload protection adds peace of mind. Capacities available from 10 ozFin to 100 lbFin [7 to 1150 Ncm]. Compatible with Mark-10 model 5i and 3i indicators (sold separately) through unique Plug & TestTM technology.

1. Compatible with the 5i and 3i digital indicators
2. Unique Plug & TestTM connector holds all calibration and configuration data
3. Outstanding overload protection
4. Interchangeable chucks (order separately)
5. NIST-traceable certificate of calibration included
6. Accuracy: ± 0.20% of full scale ±1 digit + indicatorWeight: From 1.4 lbs (0.6 kg)
7. Warranty: 3 years

Model		MR51-10Z	MR51-20Z	MR51-50Z	MR51-12	MR51-50	MR51-100
		$907.25	$907.25	$907.25	$836.00	$836.00	$836.00
Capacity x Resolution With Model 3i	ozFin	10 x 0.01	20 x 0.02	50 x 0.05	-	-	-
	lbFin	-	-	-	12 x 0.01	50 x 0.05	100 x 0.1
	kgFmm	7 x 0.005	14 x 0.01	36 x 0.05	140 x 0.1	580 x 0.5	1150 x 1
	Ncm	7 x 0.005	14 x 0.01	36 x 0.05	135 x 0.1	570 x 0.5	1150 x 1
Capacity x Resolution With Model 5i	ozFin	10 x 0.006	20 x 0.01	50 x 0.02	-	-	-
	lbFi	-	-	-	12 x 0.005	50 x 0.02	100 x 0.05
	lbFft	-	-	-	1 x 0.0005	4 x 0.002	8 x 0.005
	gFcm	700 x 0.5	1400 x 1	3600 x 2	-	-	-
	kgFmm	7 x 0.005	14 x 0.01	36 x 0.02	140 x 0.1	580 x 0.5	1150 x 0.5
	Nmm	70 x 0.05	140 x 0.1	350 x 0.2	-	-	-
	Ncm	7 x 0.005	14 x 0.01	35 x 0.02	135 x 0.1	570 x 0.5	1150 x 0.5
	Nm	-	-	-	1.35 x 0.001	5.7 x 0.005	11.5 x 0.005

G1017 Price: $166.25 In Stock

G1016-1 Price: $156.75 In Stock

G1016-2 Price: $161.50 In Stock

G1016-3 Price: $166.25 In Stock
