Mark 10 ST Torque Tool Tester


Mark 10 CTA Closure Tester / Cap Torque Tester

Series STA Torque Tool Testers present a simple, yet accurate solution for testing hand operated torque screwdrivers, wrenches, and other tools. Applications exist in manufacturing facilities in virtually every industry. The STA features a solid aluminum housing, making it rugged enough for many years of service in production or laboratory use, while a universal receptacle accepts common bits and attachments. The STA captures peak torque in both clockwise and counterclockwise directions. Note: The STA cannot be used with power, impact or air tools.

    Features

  • Outstanding value
  • Accepts many types of torque tools
  • Selectable units of measurement
  • Peak memory for clockwise and counterclockwise readings
  • RS-232 and Mitutoyo (Digimatic) outputs
  • Optional bench mounting brackets
  • Solid aluminum housing
  • 3 capacities available: 12 lbin (135 Ncm), 50 lbin (570 Ncm), 100 lbin (1150 Ncm)
  • Battery or AC operation
  • Mounting holes for bench mounting
  • Accuracy: ±0.5% of full scale ±1 digit
  • Safe overload: 150% of capacity
  • Battery: 9V (non-rechargeable), 30 hours of continuous operation
  • Weight: 4.8 lb (2.2 kg)
  • Environmental requirements: 40°F - 100°F [5°C - 45°C], <96% humidity (non-condensating)
  • Warranty: 3 years
  • CE mark

Mark 10 STA Torque Tool Tester
All Models: $1135.25

currently in stock
Shipping Weight: 10 lbs. (estimate shipping cost)
Other Force Testing Products
Other Torque Testing Products
Other Mark-10 Products


Mark 10 Communication adapter, RS-232 to USB (RSU100) Mark 10 Communication adapter, RS-232 to USB (RSU100),
Add $118.00
Mark-10  Mitutoyo Cable (09-1047) Mark-10 Mitutoyo Cable (09-1047),
Add $71.00
Mark 10 Carrying case for STA (ST002) Mark 10 Carrying case for STA (ST002),
Add $166.25
Mark 10 Carrying case for STA (ST002) Mark-10 RS-232, 9-pin Cable (09-1048A),
Add $71.00
Mark-10 MESURGauge Data Collection Software Mark-10 MESURGauge Data Collection Software (15-1004),
Add $470.25
Universal receptacle Accepts many types of torque tools and fixtures
Peak memory For clockwise and counterclockwise torque
Selectable units of measurement Measure in lbFin, kgFmm, or Ncm
Data outputs RS-232 and Mitutoyo (Digimatic)
Push-button calibration Simple and quick calibration procedure

Specifications

Model STA12 STA50 STA100
Price $1135.25
CTA12
$1135.25
CTA12
$1135.25
CTA12
Capacity x Resolution 12 x 0.01 lbFin 50 x 0.05 lbFin 100 x 0.1 lbFin
140 x 0.1 kgFmm 580 x 0.5 kgFmm 1150 x 1 kgFmm
135 x 0.1 Ncm 570 x 0.5 Ncm 1150 x 1 Ncm
Accuracy ±0.5% of full scale ±1 digit
Power AC or non-rechargeable 9V battery, with Intelligent Power Management System (IPM). IPM warns the user via a ?LO BAT? indicator and then will power off the gauge
Battery Life 30 hours of continuous use
Selectable units of measurement lbFin, kgFmm, Ncm
Outputs RS-232 - Fully configurable up to 9600 baud
Mitutoyo (Digimatic) - Serial BCD suitable for all Mitutoyo SPC-compatible devices
Safe overload 150% of full scale (display shows ?----? at 110% and above)
Weight 4.8 lb [2.2 kg
Environmental Requirements 40° F - 100°F [5°C - 45°C], <96% humidity (non-condensating)
Thermal effects: Zero: 0.03% of full scale/°C, Span: 0.01% of full scale/°C
Housing construction Aluminum
Warranty 3 years (see individual statement for further details)
