OverviewThe unique design flexibility lets you choose the model and weighing capacity you need - NTEP certified from 300 to 20,000lb / 150 to 10,000 kg. The unit utilizes a high-visibility 0.8 inch/20 mm LED digital readout
Capacity x Readability
Manufature:
IntercompNon Legal Mode:500 lb x 0.2 lb Legal For Trade: 500 lb x 0.2 lb SKU: 100661 Quick FactsWeight: 22.00 lb
|
Intercomp offers the industry’s most extensive line of crane scales, and can provide your company with a cost-effective solution to virtually every overhead industrial weighing application - ranging from 25 to 600,000 lbs/ 12.5 to 300,000 kg.
Our advanced design, value-packed with the industry’s most desired features, makes Intercomp the first choice over other electronic units. Ultra high-resolution, A/D conversion delivers unsurpassed accuracy, and digital keypad setup and calibration enhance the ease of operation.
All crane unit electronics are shock-mounted in a weatherproof case and provide maximum protection against moisture, dust and rough usage. Features include a high-visibility digital readout for easy reading of weights and large pushbutton switches for simple, trouble-free operation.
Low-cost, high performance digital crane scale for medium capacity industrial applications. The unique design flexibility lets you choose the model and weighing capacity you need - NTEP certified from 300 to 20,000 lb/150 to 10,000 kg. The unit utilizes a high-visibility 0.8 inch/20 mm LED digital readout and the efficient micro-controller delivers up to 100 hours of operation on eight (8) D-cell batteries. Crosby eye hook and bottom swivel hook.
CS1500 Crane Scales | ||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
Model | 100661 | 100662 | 100663 | 100664 | 100665 | 100666 | 184508-RFX | 184509-RFX | 184510-RFX | 184511-RFX | 184512-RFX | 184513-RFX |
Capacity Graduation |
500 x 0.2 lb 250 x 0.1 kg |
1000 x 0.5 lb 500 x 0.2 kg |
2000 x 1.0 lb 1000 x 0.5 kg |
5000 x 2.0 lb 2500 x 1.0 kg |
10,000 x 5.0 lb 5000 x 2 kg |
20,000 x 10 lb 10,000 x 5 kg |
500 x 0.2 lb 250 x 0.1 kg |
1000 x 0.5 lb 500 x 0.2 kg |
2000 x 1.0 lb 1000 x 0.5 kg |
5000 x 2.0 lb 2500 x 1.0 kg |
10,000 x 5.0 lb 5000 x 2 kg |
20,000 x 10 lb 10,000 x 5 kg |
Legal For Trade | NTEP #97-135A4 | |||||||||||
Weight | 21 lb/10kg | 25 lb/12kg | 46 lb/20 kg | 88 lb/40kg | 22 lb/10kg | 38 lb/17kg | 45 lb/20 kg | |||||
General | Zero, lb/kg On, Off, Tare, Print, Mode, Set | |||||||||||
Display | 5 1/2 Digit, 0.8 Inch, 20 mm high LED Display | |||||||||||
Indicator | lb/kg, Gross, Net, Total and Peak Hold | Intercomp 101225-RFX | ||||||||||
Battery Life | Standard Alkaline D-Cell Batteries Last up to 90 Hours in Scales | |||||||||||
Batteries | 8 "D" Size disposable Alkaline dry cells or rechearable nicad cells (not included) | |||||||||||
Resolution | 20 bit A/D delivers over 1,000,000 internal counts | |||||||||||
Auto-Zero | Satisfies all NIST/OIML requirements | |||||||||||
Zero | Up to 100% excluding NIST/OIML units | |||||||||||
Humidity | 10 to 95% non-condensing | |||||||||||
Temperature | Operating -4° to 140°F/- 20° to 60°C | |||||||||||
Filtering | 6-Pole, 10 Hertz low pass | |||||||||||
Speed | 3 Seconds to typical reading | |||||||||||
Accuracy | +/- 0.1% of reading | |||||||||||
Maximum Overload | 500% of capacity | |||||||||||
Enclosure | NEMA IV cast aluminum case | |||||||||||
Hook or Eye | Crosby-Laughlin or equivalent | |||||||||||
USB/RS232 Output | - | YES | ||||||||||
Options | RS 232 Serial Output (sold separately) LED Display (sold separately) Direct 120/220 vold power supply (sold separately) |
