OverviewThe CHATILLON® PDT Series floor platform scale features a large, easy-to-read 13-inch (330 mm) dial with knife-edge pointer for accurate measurements.
Capacity x Readability
Manufature:
Chatillon AmetekNon Legal Mode:65 lb x 2 oz Legal For Trade: 65 lb x 2 oz Pan Size 17 x 12 in SKU: PDT-065 Quick Facts
|
The CHATILLON® PDT Series floor platform scale features a large, easy-to-read 13-inch (330 mm) dial with knife-edge pointer for accurate measurements. The PDT Series is a Class III “Legal for Trade” scale. Scales feature a large 17 x 12-inch (430 x 305 mm) steel platform. Designed for floor use, the PDT features a rugged cast-iron base with heavy-gauge steel platform for excellent stability. The scale’s mounting feet are adjustable. Options include a stainless steel platform and quick tare knob. Tare adjustments may be made up to 10% of rated capacity. The scale’s head cover and column back are removable for easy access to the dial mechanism and the dashpot. Scale is assembled on-site with standard tools. Assembly does not affect calibration.
Features
Model | PDT-065 | PDT-130 | PDT-260 | |||
---|---|---|---|---|---|---|
Capacity x Accuracy | 65 lb x 2 oz | 130 lb x 4 oz | 260 lb x 8 oz | |||
Legal for Trade | Class III CC #90-078 | |||||
Base Size | 17 x 12 inch | 17 x 12 inch | 17 x 12 inch | |||
dial | 13-inch | 13-inch | 13-inch | |||
Range | 0 - 62 lb | 63 - 65 lb | 0 - 125 lb | 126 - 130 lb | 0 - 250 lb | 251 - 260 lb |
Scale Divisions | 0 - 500 | 501 - 2000 | 0 - 500 | 501 - 2000 | 0 - 500 | 501 - 2000 |
Tolerance Division | ±1/2 d | ±1 d | ±1/2 d | ±1 d | ±1/2 d | ±1 d |
Tolerance Weight | ±1 oz | ±2 oz | ±2 oz | ±4 oz | ±4 oz | ±8 oz |
Tolerance Weight | ±0.10 % | ±0.19 % | ±0.10 % | ±0.19 % | ±0.10 % | ±0.19 % |
Safe Overload | 120% of rated capacity | |||||
Ultimate Overload | 125% of Rated Capacity | |||||
Display | Single Reading | |||||
Operating Temperature | 45º to 104º F (7º to 40ºC) | |||||
Storage Temperature | -4º to 104ºF | |||||
Instrument Weights | 50 lbs (23 kg) | |||||
Shipping Weight | 60 lbs (28 kg) |
Image | Name | Price | ||
---|---|---|---|---|
Chatillon PDT-065 Mechanical Platform Scale, 65 lb x 2 oz
SKU: PDT-065 Capacity x Readability : 65 lb x 2 oz Legal For Trade: 65 lb x 2 oz Pan Size: 17 x 12 in More Info |
$1,214.23 |
|||
Chatillon PDT-130 Mechanical Platform Scale, 130 lb x 4 oz
SKU: PDT-130 Capacity x Readability : 130 lb x 4 oz Legal For Trade: 130 lb x 4 oz Pan Size: 17 x 12 in More Info |
$1,214.23 |
|||
Chatillon PDT-260 Mechanical Platform Scale, 260 lb x 8 oz
SKU: PDT-260 Capacity x Readability : 260 lb x 8 oz Legal For Trade: 260 lb x 8 oz Pan Size: 17 x 12 in More Info |
$1,214.23 |
|
