Reliable Battery-backed Performance
The 381 Synergy has an ABS plastic enclosure with two different battery options, enabling you to create the ideal portable weighing solution for your operations. The AA battery-operated model provides up to 40 hours of operation and has an IP54 rating. The Nickel Metal Hydride (NiMH) battery-operated model provides up to 80 hours of operation with an IP66 rating. Both battery versions have an optional external power adapter.

Indicator
• LCD display
• Battery powered
• Push-button and keyed tare
• Two communication ports
• Five tactile buttons
• Configurable print formats
• ABS enclosure

Options
• Time/date
• External power supply

Reliable Battery-backed Performance
The 381 Synergy has an ABS plastic enclosure with two different battery options, enabling you to create the ideal portable weighing solution for your operations. The AA battery-operated model provides up to 40 hours of operation and has an IP54 rating. The Nickel Metal Hydride (NiMH) battery-operated model provides up to 80 hours of operation with an IP66 rating. Both battery versions have an optional external power adapter.

Indicator
• LCD display
• Battery powered
• Push-button and keyed tare
• Two communication ports
• Five tactile buttons
• Configurable print formats
• ABS enclosure

Options
• Time/date
• External power supply

Four NSF-approved caster-designed wheels enable the operator to move the scale easily and effortlessly. Use the indicator stand with Rice Lake’s IQ Plus® 390-DC indicator and you have a visible weighing system at your command, anywhere you can take it.

• Kits Include: Frame, two swivel and two fixed zinc plated steel NSF approved wheels (75 lb max. load capacity), indicator stand
• Live siderails
• Top access foot adjustment holes
• Holes are 1/2-13 threaded for lifting scale
• 4 adjustable stainless steel SUREFOOT™ support feet
• TuffSeal® JB4SS stainless steel, NEMA Type 4X junction box with signal trim card
• Treaded top plate
• Alloy steel load cells

With the 120, there is no need to sacrifice quality for price. This digital weight indicator is designed to be a reliable, cost-effective solution for material handling or shipping and receiving applications.

The 120 drives up to four 350Ù load cells. And three-stage digital filtering provides stable, accurate weight data. The 120’s five-button tactile front panel and easy-to-read LED display help to make scale operations effortless. Two independent communication ports provide full EDP and print ticket programmability.

Purchase the 120 alone, or buy it with one of our quality bench or floor scales. We’ve paired the 120 with a bench scale as an economic bundled option. The 17" x 21" stainless steel platform is an ideal size for a range of applications.

Additionally, we offer a floor scale and indicator package that combines the 120 with the Summit 3000 Floor Scale. They arrive at your location corner trimmed and calibrated for 5000 divisions.

• Large 0.8" (20 mm) Red Light Emitting Diode (LED) display
• 30 updates per second selectable
• Power for four 350Ù load cells
• Primary/secondary unit configuration: lb, kg, ounces, grams
• 5-button operation
• Two independent communication ports: (1) full duplex, (1) unidirectional or active 20 mA current loop
• Standardized EDP command sets
• Programmable ticket format for up to 180-character printout
• Full front-panel digital calibration and configuration
• Tilt stand
• Three-stage digital filtering
• Consecutive transaction numbering
• Time and date (volatile)

Options/Accessories
• External disconnect
• Load cell plug
• Revolution III Scale Software
• Additional operating manual

Where Economy and Performance Meet With the 120 Plus, there is no need to sacrifice quality for price. This digital weight indicator is designed to be a reliable, cost-effective solution for material handling or shipping and receiving applications. The 120 Plus drives up to four 350Ù load cells. Three-stage digital filtering provides stable, accurate weight data. The 120 Plus’s tactile front panel and easy-to-read LCD display help to make scale operations effortless. Two independent communication ports provide full EDP and print ticket programmability.

Purchase the 120 Plus alone, or buy it with one of our quality bench or floor scales. We offer a floor scale and indicator package that combines the 120 Plus with the Summit 3000 Floor Scale. They arrive at your location corner trimmed and calibrated for 5000 divisions.

• Large 0.8 in (20 mm) LCD display with back light
• Powered with rechargeable battery or wall adapter
• Power save feature for 700 hours of battery life
• Two setpoints with delay and timer selections (requires option)
• Three digital inputs (requires option)
• Ten stored tare values
• Display hold based on 3 second average
• Tilt stand
• Time and date

• Revolution® III Scale Software
• Digital I/O card
• 15 pin interface cable

IQ plus 210 digital weight indicator is known for its performance with the IQ plus 2100 bench scale, but its the ideal replacement indicator for any bench scale in portioning, ingredient weighing and general industrial applications. Its large, vibrant display rivals any other in its class as well as the ability to show pounds and ounces simultaneously.

Its rugged design includes a NEMA Type 4X stainless steel enclosure that protects electronics from frequent washdown, and sealed, stainless steel buttons resist damage in abusive environments.

Its so easy to use—all operations are controlled with just two buttons, zero and units. For ultimate simplicity, the units button can be disabled, virtually eliminating operator errors. Auto or stream print modes are standard, or mount an optional print button on the top of the enclosure for connection to a printer or PC. Configuration can be completed through the indicators front panel, EDP port or from a personal computer with Revolution™ software.

• Piezo switch technology with stainless steel buttons (zero and units)
• LED display, 0.8 in, six-digit, seven-segment
• NEMA Type 4X stainless steel enclosure
• Status annunciators: lb, kg, oz, g, negative, motion, center of zero
• Displays units in decimals lb, kg, oz, lb and oz and grams
• One full duplex RS-232 port
• Two digital inputs for remote zero, print and units
• PreVent™ breather vent
• Configurable with Revolution® software

Rice Lake’s Legend Series combines industrial strength with innovative features to deliver the best in performance and value

Advance to Rice Lake’s Legend Series With NEMA Type 4X, stainless steel enclosure and advanced gasket system, the industrial-strength Legend Series is built for dirty, wet environments and demanding workplaces, inside or out. Choose between large, ultra-bright LED or LCD 0.8-inch displays with 6-digits and sharp contrast for superior display visibility.

Advanced circuitry withstands electrical noise, power disturbances and transient spikes that are common to industrial applications. The Legend Series’ six-button tactile keypad allows for quick navigation and programming. The Legend Plus Series offers a full numeric keypad.

The Legend Series offers a valuable solution for a variety of applications, from basic weighing to batching. Built-in gross/net modes provide quick flexibility for everyday needs. Also utilize the 480’s custom ticket printing to modify gross, net and setpoint tokens for a tailored print format.

Power
• Standard AC power for stationary applications
• Optional internal battery for portability, with power-saving modes for long-lasting operation

Options
• Analog output with 0-10 VDC, 0-20mA, 4-20mA; configurable for positive and negative value tracking
• Relay output with two inputs and four dry contact relays
• USB and Ethernet TCP/IP board supports server and client connections

Functions
• Internal clock with time stamp can be positioned in configurable print formats
• Unit ID number can be entered by the operator to uniquely identify each scale or job
• Eight batch steps with latched or continuous outputs based on gross, net or delay values

Features
• Two serial ports: one on demand and one continuous or two on demand
• Single scale input from light capacity bench scales to heavy capacity industrial scales
• Local/Remote: add an additional indicator as a secondary display in a remote location

• 0.8in (20mm), 6-digit, 7-segment display
  • LED, 480 and 480 Plus
  • LCD, 482 and 482 Plus
• Time and date, battery backed
• Local/remote operation
• Numeric keypad (480 Plus and 482 Plus)
• Keypad entries and setpoint values (480 Plus and 482 Plus)
• Two independent serial ports, RS-232 and 20mA
• NEMA Type 4X/IP66 stainless steel washdown enclosure
• Password protection for user and configuration changes
• Selectable conversion rate and display update rate
• Hardware or audit trail metrology sealing
• Programmable ticket formats for gross, net, accumulator, and setpoints
• Five continuous stream formats
• Adapter filter or rolling average filter
• Configurable with Revolution® software
• Operator functions through menu for audit trail, preset tare, unit ID, accumulator, time and date, setpoints, communications, and print formats
• Eight setpoints, sequenced batch engine

Options/Accessories
• Analog output, 0-10VDC, 0-20mA, 4-20mA, selection for 20% offset
• Relay output, two digital inputs, four dry contact relays (supports two boards)
• Battery, rechargeable lithium ion
  480: power for 18 hours of battery life on one 350 ohm load (LCD current draw vs LED current draw)
  482: power for 40 hours of battery life on one 350 ohm load Power-saving modes for sleep and wake-up threshold
• Ethernet TCP/IP and USB interface

Advance to Rice Lake’s Legend Series—classic Rice Lake quality and design with innovative features for tomorrow. As the flagship of Rice Lake’s Legend Series, the 480 and 482 digital weight indicators have been designed to provide the very best in performance and value.

With stainless steel enclosures and advanced gasket systems, the industrial-strength Legend Series is built for dirty, wet environments and demanding workplaces, inside or out. Advanced circuitry also withstands electrical noise, power disturbances and transient spikes that are common to industrial applications.

Rice Lake’s Legend Series is the industry’s first choice for readability. With a choice between large, ultra-bright LED or LCD displays, 0.8 inch digits and sharp contrast, these indicators provide superior display visibility. The 480’s six-button tactile keypad allows for quick navigation and programming. Advance to the Plus Series for a full numeric keypad.

Connect to a printer, PC or remote display and make use of configurable print formats, time and date function, and local/remote capability. A standard lithium ion rechargeable battery allows operation from remote locations, such as a portable work station.

• LED or LCD backlit display, 0.8 in (20 mm), 6-digit, 7-segment
• Time and date, battery backed
• Local/remote operation
• Numeric keypad (480 Plus/482 Plus)
• Keyed entries for tare and setpoint values (480 Plus/482 Plus)
• 2 independent serial ports, RS-232 and 20 mA
• Programmable ticket formats for gross, net, accumulator and setpoints
• 5 continuous stream formats
• Operator functions through menu for audit trail, preset tare, unit ID, accumulator, time and date, setpoints, communications and print formats
• 8 setpoints, sequenced batch engine
• Configurable with Revolution® software
• Please call (800)832-0055 for Models with analog, relay, USB or Ethernet outputs

Call Us (800)832-0055 for these Options
• Analog output, 0-10 VDC, 0-20 mA, 4-20 mA, selection for 20% offset
• Relay output, 2 digital inputs, four dry contact relays (supports 2 boards)
• Ethernet TCP/IP and USB interface (requires cable)
• Battery, rechargeable lithium ion Power for 40 hours of battery life on one 350 ohm load Power-saving modes for sleep and wake-up threshold
