Intercomp CS1500 100663 Crane Scale with remote, 2000 x 1.0 lb

Features

Intercomp offers the industry’s most extensive line of crane scales, and can provide your company with a cost-effective solution to virtually every overhead industrial weighing application - ranging from 25 to 600,000 lbs/ 12.5 to 300,000 kg.

Our advanced design, value-packed with the industry’s most desired features, makes Intercomp the first choice over other electronic units. Ultra high-resolution, A/D conversion delivers unsurpassed accuracy, and digital keypad setup and calibration enhance the ease of operation.

All crane unit electronics are shock-mounted in a weatherproof case and provide maximum protection against moisture, dust and rough usage. Features include a high-visibility digital readout for easy reading of weights and large pushbutton switches for simple, trouble-free operation.

Low-cost, high performance digital crane scale for medium capacity industrial applications. The unique design flexibility lets you choose the model and weighing capacity you need - NTEP certified from 300 to 20,000 lb/150 to 10,000 kg. The unit utilizes a high-visibility 0.8 inch/20 mm LED digital readout and the efficient micro-controller delivers up to 100 hours of operation on eight (8) D-cell batteries. Crosby eye hook and bottom swivel hook.

Specifications

CS1500 Crane Scales
Model	100661	100662	100663	100664	100665	100666	184508-RFX	184509-RFX	184510-RFX	184511-RFX	184512-RFX	184513-RFX
Capacity Graduation	500 x 0.2 lb 250 x 0.1 kg	1000 x 0.5 lb 500 x 0.2 kg	2000 x 1.0 lb 1000 x 0.5 kg	5000 x 2.0 lb 2500 x 1.0 kg	10,000 x 5.0 lb 5000 x 2 kg	20,000 x 10 lb 10,000 x 5 kg	500 x 0.2 lb 250 x 0.1 kg	1000 x 0.5 lb 500 x 0.2 kg	2000 x 1.0 lb 1000 x 0.5 kg	5000 x 2.0 lb 2500 x 1.0 kg	10,000 x 5.0 lb 5000 x 2 kg	20,000 x 10 lb 10,000 x 5 kg
Legal For Trade	NTEP #97-135A4
Weight	21 lb/10kg		25 lb/12kg	46 lb/20 kg		88 lb/40kg	22 lb/10kg			38 lb/17kg		45 lb/20 kg
General	Zero, lb/kg On, Off, Tare, Print, Mode, Set
Display	5 1/2 Digit, 0.8 Inch, 20 mm high LED Display
Indicator	lb/kg, Gross, Net, Total and Peak Hold						Intercomp 101225-RFX
Battery Life	Standard Alkaline D-Cell Batteries Last up to 90 Hours in Scales
Batteries	8 "D" Size disposable Alkaline dry cells or rechearable nicad cells (not included)
Resolution	20 bit A/D delivers over 1,000,000 internal counts
Auto-Zero	Satisfies all NIST/OIML requirements
Zero	Up to 100% excluding NIST/OIML units
Humidity	10 to 95% non-condensing
Temperature	Operating -4° to 140°F/- 20° to 60°C
Filtering	6-Pole, 10 Hertz low pass
Speed	3 Seconds to typical reading
Accuracy	+/- 0.1% of reading
Maximum Overload	500% of capacity
Enclosure	NEMA IV cast aluminum case
Hook or Eye	Crosby-Laughlin or equivalent
USB/RS232 Output	-						YES
Options	RS 232 Serial Output (sold separately) LED Display (sold separately) Direct 120/220 vold power supply (sold separately)						Printer

Other Models

Other Intercomp CS1500

Image	Name			Price
	Intercomp CS1500 100661 Crane Scale with remote, 500 x 0.2 Ib SKU: 100661 Capacity x Readability : 500 lb x 0.2 lb Legal For Trade: 500 lb x 0.2 lb More Info			$1,434.95
	Intercomp CS1500 184500-RFX Legal for Trade Crane Scale with LCD Display, 500 x 0.2 Ib SKU: 184500-RFX Capacity x Readability : 500 lb x 0.2 lb Legal For Trade: 500 lb x 0.2 lb More Info			$1,885.50
	Intercomp CS1500 184514-RFX Legal for Trade Crane Scale with LED Display 500 x 0.2 lb SKU: 184514-RFX Capacity x Readability : 500 lb x 0.2 lb Legal For Trade: 500 lb x 0.2 lb More Info			$1,885.50
	Intercomp CS1500 100662 Crane Scale with remote, 1000 x 0.5 lb SKU: 100662 Capacity x Readability : 1000 lb x 0.5 lb Legal For Trade: 1000 lb x 0.5 lb More Info			$1,614.95
	Intercomp CS1500 184501-RFX Legal for Trade Crane Scale with LCD Display 1000 x 0.5 lb SKU: 184501-RFX Capacity x Readability : 1000 lb x 0.5 lb Legal For Trade: 1000 lb x 0.5 lb More Info			$1,885.50
	Intercomp CS1500 184515-RFX Legal for Trade Crane Scale with LED Display 1000 x 0.5 lb SKU: 184515-RFX Capacity x Readability : 1000 lb x 0.5 lb Legal For Trade: 1000 lb x 0.5 lb More Info			$1,885.50
	Intercomp CS1500 100663 Crane Scale with remote, 2000 x 1.0 lb SKU: 100663 Capacity x Readability : 2000 lb x 1 lb Legal For Trade: 2000 lb x 1 lb More Info			$1,614.95
	Intercomp CS1500 184502-RFX Legal for Trade Crane Scale with LCD Display 2000 x 1 lb SKU: 184502-RFX Capacity x Readability : 2000 lb x 1 lb Legal For Trade: 2000 lb x 1 lb More Info			$1,885.50
	Intercomp CS1500 184516-RFX Legal for Trade Crane Scale with LED Display 2000 x 1 lb SKU: 184516-RFX Capacity x Readability : 2000 lb x 1 lb Legal For Trade: 2000 lb x 1 lb More Info			$1,975.00
	Intercomp CS1500 184503-RFX Legal for Trade Crane Scale with LCD Display 5000 x 2 lb SKU: 184503-RFX Capacity x Readability : 5000 lb x 2 lb Legal For Trade: 5000 lb x 2 lb More Info			$2,425.50
	Intercomp CS1500 184517-RFX Legal for Trade Crane Scale with LED Display 5000 x 2 lb SKU: 184517-RFX Capacity x Readability : 5000 lb x 2 lb Legal For Trade: 5000 lb x 2 lb More Info			$2,595.00
	Intercomp CS1500 100665 Crane Scale with remote, 10,000 x 5.0 lb SKU: 100665 Capacity x Readability : 10000 lb x 5 lb Legal For Trade: 10000 lb x 5 lb More Info			$1,794.95
	Intercomp CS1500 184504-RFX Legal for Trade Crane Scale with LCD Display 10000 x 5 lb SKU: 184504-RFX Capacity x Readability : 10000 lb x 5 lb Legal For Trade: 10000 lb x 5 lb More Info			$2,425.50
	Intercomp CS1500 184518-RFX Legal for Trade Crane Scale with LED Display 10000 x 5 lb SKU: 184518-RFX Capacity x Readability : 10000 lb x 5 lb Legal For Trade: 10000 lb x 5 lb More Info			$2,595.00
	Intercomp CS1500 100666 Crane Scale with remote, 20000 x 10 lb SKU: 100666 Capacity x Readability : 20000 lb x 10 lb Legal For Trade: 20000 lb x 10 lb More Info			$2,605.00

Optional Accessories

more info	Intercomp Part 340105 Thermal Printer, Roll, Battery or AC Operation for Intercomp CS750, CS1500 & CS3000, TL6000 & CW250 & PT600 (Need 101165 cable) more info Price: $535.50 In Stock This compact, fully featured, portable thermal printer is the perfect printer for your weighing system application. The small, lightweight design ensures this printer can be used on the go, and its high speed, low noise mechanism is perfect for any environment. This printer features a long life print head with high reliability, easy paper handling, a large capacity Lithium-ion rechargeable battery, and your choice of paper diameters up to 40mm. GENERAL SPECIFICATIONS Interface Serial Interface Printing System Direct Thermal Printing Printing Speed 50mm/Sec Character matrix ASCII Code, Alphanumeric Characters, International Characters, Windows Code Page Characters Per Line 32 - 42 Characters per Line, Two Font Size Choices Paper Width 58 +/-0.5mm Recommended Paper TF50-KS-E2D (Nippon Paper) External dimensions 4.5"x4"x2.5"/116W x 104L x 63Hmm 5°C - 40°C, 41°F - 104°F Weight Less Than 1lb Printer Includes: Printer 1 Sample Roll of Paper AC Adapter Battery Serial Cable Fully compatable with Intercomps CS750 Crane Scale, CS1500 Crane Scale, CS3000 Crane Scales, CS5000 Crane Scales, TL6000 Tension Link Scales, CW250 Cargo Scales, TB830 Twin Beam Scales, US840 U-Beam Scales, PT300 Wheel Load Scales, LP600 Low-Profile Wheel Load Scales, GP1000 Indicator, GP1200 Indicator, GP2000 Indicator, GP2000EM Indicator and the MS450 Mining Scale Systems.

more info	Intercomp Part 101231, Cable, to Thermal Printer, 15 ft. more info Price: $145.00 In Stock Cable for Thermal Printer, 15 ft.

more info	Intercomp Part 101233, Cable, RS232/USB output, 15 ft. more info Price: $149.00 In Stock Cable, serial output, 15 ft.

Overview

Quick Facts

Optional Warranty

Features

Specifications

Other Models

Optional Accessories

More Images


The unique design flexibility lets you choose the model and weighing capacity you need - NTEP certified from 300 to 20,000lb / 150 to 10,000 kg. The unit utilizes a high-visibility 0.8 inch/20 mm LED digital readout more ...
