The OHAUS Pioneer Series of analytical and precision balances (Internal and Extenal Calibration models) are designed for basic routine weighing in a variety of laboratory, industrial and education applications. With the right combination of performance and features, the OHAUS Pioneer offers uncomplicated performance for all your basic weighing needs. more ... |
Features
The new Ohaus Pioneer PX series Laboratory Balances is the latest addition of Ohauss Laboratory Scales. Ohaus to the existing Pioneer Plus series and simply gave it a modern upgrade. They took all the wonderful Features and made them better.
The Best Balance For Basic Weighing!
The OHAUS Pioneer Series of analytical and precision balances are designed for basic routine weighing
in a variety of laboratory, industrial and education applications. Now with both internal and external
calibration models and the right combination of performance and features, the OHAUS Pioneer offers
uncomplicated performance for all your basic weighing needs.
Standard Features Include:
- Easy to Clean Analytical Draftshield - Pioneers draftshield is designed with all glass panels, including three sliding doors. All panels are easy to remove and replace, and together with a stainless steel bottom, make it fast and easy to clean.
- Upfront Level Indicator - Pioneer has been designed with an up-front level indicator, so that users can quickly ensure the balance is level prior to use
- Bright Backlit Display - The bright backlit LCD display is easy-to-view in any environment.
- Selectable Environmental Settings - Three filter modes and adjustable zero tracking adjust balance sensitivity to environmental disturbances, or application requirements.
Removable Doors Provide Convenient Access and Easy Cleaning
To address the ease of cleaning requirement often expressed by routine users,
Pioneers draftshield has been designed with easy to remove doors and panels.
Disassembly takes just seconds and all components including the balance housing can
be quickly wiped clean.
Periodic cleaning made easy helps avoid sample
contamination and extends product life. In addition,
a standard in-use cover provides added protection
against accidental spillage and helps minimize the
chance of damage to the display and keypad.
Should breakage occur, each replacement door or panel can be installed in
seconds.
Backlit Display Bolsters Visibility
The bright backlit LCD display provides ample lighting, making the display
very easy-to-view in laboratories with dim lighting
Selectable Environmental Settings For Working in
Practically Any Condition
To help adapt the balance to real life working conditions, Pioneer is
designed with selectable environmental settings. When working in harsh
environments, the balance can be adjusted to compensate for vibrations
and other disturbances. Conversely, the balance can be adjusted for working
in slow filling applications where sensitivity is a must.
Standard Features:
- Integral Security Bracket: Allows you to secure your balance to a workstation to prevent unwarranted movement or theft
- RS232 Interface: Pioneers RS232 allows connection to an Ohaus printer or a computer. Sends Balance ID plus spaces for recording User ID, Project ID, time and date
- Integral Menu Lock: A combination of software and a mechanical switch locks menus, including calibration
- Weigh-Below Hook: Pioneers built-in weigh-below hook allows you to suspend an item below the balance to calculate density/specific gravity
- Up-Front Level Indicator: A quick glance at the up-front level indicator helps to ensure that the balance is level prior to each use
- Multiple Application Modes and Units: Pioneer features basic weighing, parts counting and percent weighing, density weighing, and dynamic weighing and 15 international weighing units including one custom unit
- Backlit Display: Enables optimal viewing of results in various lighting conditions
Specifications
Model with Internal Calibration |
PX85 30475733 |
PX225D 30475734 |
PX84 30429837 |
PX124 30429838 |
PX224 30430053 |
PX163 30429839 |
PX323 30429840 |
PX523 30430054 |
PX623 30699092 |
PX1602 30430055 |
PX2202 30429841 |
PX3202 30429842 |
PX4202 30429843 |
PX6202 30699094 |
PX2201 30430056 |
PX4201 30429844 |
Model with External Calibration |
|
|
PX84/E 30429845 |
PX124/E 30429846 |
PX224/E 30429847 |
PX163/E 30429848 |
PX323/E 30429849 |
PX523/E 30430057 |
PX623/E 30699093 |
PX1602/E 30430058 |
PX2202/E 30429850 |
PX3202/E 30429851 |
PX4202/E 30429852 |
PX6202/E 30699095 |
PX2201/E 30430059 |
PX4201/E 30429853 |
Capacity x Resolution |
82 g x 0.01 mg |
82 g x 0.01 mg 220 g x 0.1 mg |
82 g x 0.1 mg |
120 g x 0.1 mg |
220 g x 0.1 mg |
160 g x 1 mg |
320 g x 1 mg |
520 g x 1 mg |
620 g x 1 mg |
1600 x 0.01 g |
2200 x 0.01 g |
3200 x 0.01 g |
4200 x 0.01 g |
6200 x 0.01 g |
2200 x 0.1 g |
4200 x 0.1 g |
Stabilization Time (s) |
10 s |
4 s |
2 s |
1 s |
Linearity (±g) |
0.0001 g |
0.0002 g |
0.002 g |
0.02 g |
0.2 g |
Linearity (±g) |
0.00003 g |
0.00003 g 0.0001 g |
0.0001 g |
0.001 g |
0.01 g |
0.1 g |
Pan Diameter (in / mm) |
3.15 in / 80 mm |
3.54 in / 90 mm |
4.72 in / 120 mm |
7.09 in / 180 mm |
Draft Shield |
YES |
YES |
YES |
YES |
YES |
YES |
YES |
YES |
YES |
- |
- |
- |
- |
- |
- |
- |
Warranty |
2 Years |
Interface |
RS232, USB |
Units |
Milligram, Gram, Kilogram, Ounce, Pound, Carat, Pennyweight, Ounce Troy, Grain, Newton, Hong Kong Tael,Singapore Tael, Taiwan Tael, Momme, Tical (MM), Mesghal, Tola (India), 1 custom unit |
Product Length x Width x Height |
12.6 x 8.2 x 13.3 in |
12.6 x 8.2 x 13.3 in |
12.6 x 8.2 x 3.9 in |
Shipping weight (lbs) |
15.4 lb |
15.4 lb |
11 lb |
Power |
Input Voltage (VAC) 100-240 V Frequency: 50-60 Hz |
