OverviewOutstanding flexibility and performance with many standard features; ideal universal replacement indicators for whatever you weigh or count. Technician-friendly set-up and Sustained Accuracy™ make these ideal for new installations or field replacement using existing platforms or load cells. Wide range of standard optional features. |
Outstanding flexibility and performance with many standard features; ideal universal replacement indicators for whatever you weigh or count. Technician-friendly set-up and Sustained Accuracy™ make these ideal for new installations or field replacement using existing platforms or load cells. Wide range of standard optional features.
Ship pre-matched when ordered with any Pennsylvania base or platform. Whatever you count or weigh, a new, technologically-advanced 7500 or 7600 series digital weight indicator will exceed your expectations.
Features
Practical Technology Breakthrough
System Data Communications
Technical Specifications
Physical Dimensions
Approvals
Warranty
The parts and components of this Pennsylvania Scale product are warranted for four years from date of retail delivery against defects in materials or workmanship, subject to the terms and conditions of our standard warranty.
7500+ indicator
The 7500+ indicator features a high-resolution display, singlebutton operation, and Automatic Sample Update™ for more productive weighing and counting
Feature Specifications | 7500/4 | 7600/4 |
---|---|---|
Legal For Trade | NTEP 10,000 divisions, Canadian Weights & Measures 10,000 divisions | |
Shipping systems | UPS Worldship, FedEX, DHL, and other output emulation for plug-and-play integration | |
Weigh in 2 units | lb, kg, oz, lb-oz, dwt, oz T, custom (specify other than lb/kg labeling) | |
Outputs | RS-232 | |
Display | Red 0.56" high intensity LED | |
One button counting w/ Sample Update™ | YES | YES |
300 part weight memories | YES | |
Accumulate count or weight | YES | |
%-Accuracy/%-Error display | YES | |
(2) Weighing units | YES | YES |
Input and display of Average Part Weight, Tare Weight, 14-digit numeric I.D., Time/Date | YES | |
Dual Base Option sample-to-bulk counting (requires optional DB 2nd base input) | YES | |
Ethernet option | YES | YES |
Solid State Relay Option for batching | YES | |
Bidirectional programmable outputs | 1 | 1 |
Time/Date with battery back-up | YES | |
Sequential Batching (Count/Weigh) | C/W | |
Remote Display default setting | YES | YES |
Panel Mount Option | YES | YES |
DC power Option, 30 hours/charge Integrated, HD power cord, functions like a U.P.S. back-up power supply | YES | YES |
Warranty | Four-year | Four-year |
DIMENSIONS | 9" (W) x 6.44" (H) x 4" (D) without U-bracket 11" (W) x 7" (H) x 4" (D) on U-bracket stand with knobs (allow 1" space behind for cable fittings) |
$479.00 |
|
