OverviewThe more precious or limited the sample, the greater the challenge to use it for analysis. The narrow sensor shaft of micro pH sensors fits in nearly every sample container and enables measurements of sample volumes down to the lower ranges.
|
Performance to Trust Easy to Use Built to Last InLab® Sensor Technology Proven Reliability
Measurements have to be fast, precise and reproducible. Tried and trusted technologies combined with state-of-the-art production processes guarantee highest performance for every InLab sensor, providing reliable results at any time.
All InLab sensors are shipped ready to use. Everything you need for your measurement comes together with the sensor. Your work in the lab will be simplified by application specific sensors, automatic recognition of ISM sensors and the spillfree wetting cap
The thought-out InLab sensor construction as well as the highquality materials used for manufacturing guarantee high robustness even in harsh applications. The versatile sensor portfolio ensures the perfectly suited sensor for every application, a match that greatly extends the lifetime of the products.
The variety of electrochemical sensors is as diverse as the applications they are used for. Only the right combination of high-quality materials, tried-and-trusted technologies, and the shape of the membrane make a sensor perfectly suited for a specific application.
Liquid filled electrodes are reliable workhorses, constructed for efficient pH measurements in daily laboratory use of a wide application range. For more complex sample matrices like emulsions or biological media, electrodes with a sleeve junction are recommended.
Electroplating is a common technique used to coat metals in order to add desired properties to them. Strong acids and bases are needed for this process and the robust HA glass of the InLab Routine Pro-ISM is ideal for this application as it covers the whole pH range with an extremely low alkali error.
Model | Ultra-Micro-ISM 30244732 |
Micro 51343160 |
Micro Pro-ISM 51344163 |
Semi-Micro 51343165 |
Flex-Micro 51343164 |
|
---|---|---|---|---|---|---|
pH range | 1 - 11 | 0 – 14 | 0 – 14 | 0 – 12 | 0 – 14 | |
Temperature range | 0 to 80 °C | 0 to 80 °C | 0 to 100 °C | 0 to 100 °C | 0 to 80 °C | |
Temperature probe | - | - | NTC 30 kΩ | - | - | |
Type of membrane glass | LoT | U | U | A41 | U | |
Membrane resistance (25°C) | < 700 MΩ | < 1000 MΩ | < 300 MΩ | < 600 MΩ | < 600 MΩ | |
Type of junction | Ceramic | Ceramic | Ceramic | Open junction | Porous PTFE | |
Reference system | ARGENTHAL™ with Ag+-trap | ARGENTHAL™ with Ag+-trap | ARGENTHAL™ with Ag+-trap | ARGENTHAL™ with Ag+-trap | ARGENTHAL™ with Ag+-trap | |
Reference electrolyte | FRISCOLYT-B® | 3 mol/L KCl | 3 mol/L KCl | XEROLYT®EXTRA Polymer | Gel | |
Cable and connection | MultiPin™ | S7 | MultiPin™ | S7 | 1.0 m cable; BNC | |
Shaft material | Glass | Glass | Glass | Glass | Epoxy | |
Shaft length | 40 mm | 60 mm | 130 mm | 100 mm | 180 mm | |
Shaft diameter | 3 mm | 3 mm | 5 mm | 6 mm | 6 mm | |
Shaft diameter | 15 µL | 45 µL | 100 µL | 100 µL | 500 µL | |
Common specifications | Type of electrode: pH-combination |
$739.20 |
