WLC-X7 Precision Balances
The WLC.X7 series represents a new advanced level for precision balances. The X7 series balances feature the latest generation capacitive display providing the maximum comfort of use, available right at your fingertips. Ease of operation, clear menu and practical arrangement of the display guarantee the best ergonomics for your everyday tasks. A wide array of available interfaces facilitate selection of the most optimal means for communication.

Weighing Data Managementn The X7 series balances offer unlimited possibilities for cooperation with external devices, providing printing, copying, archiving and data transfer.
Built-in IR sensors allow numerous operations (e.g. tarring, transmitting the result to a printer or selecting successive steps of a particular process, etc.) to be performed handsfree, by simply moving a hand across the sensor. The housing is made of plastic, and the pan is made of stainless steel.
USB interface facilitates quick transfer and copying of any results of your work (measurements, reports, databases) to other balances. Network management of the weighing data increases effectivity, productivity and safety of the important data to the maximum.
WLC.X7 scales are equipped with many communication interfaces: 2 x RS 232, USB type A, USB type B and Wireless Connection.

Databases in X7 series balances In new WLC.X7 series balances the information system is based on 7 databases which allow several users to work with database storing several products. The registered weighing results can be subject to further analysis. The data is registered in 7 databases:

• Users (up to 100 users)
• Products (up to 5 000 products)
• Weighments (up to 50 000 weighments)
• Packaging (up to 100 packaging types)
• Formulas (up to 100 formulas)
• Clients (up to 1000 clients)
• ALIBI memory (up to 512 000 weighments)

. The X7 series features option of making reports on formulas (up to 500 reports).

Personalization taken to the next level
The X7 is the only balance available on the market that provides a user with the option to design display using wide selection of widgets. Customised display of X7 series offers direct access to the results of your work and other important information directly from the home screen.

ALIBI Memory The X7 series balances feature ALIBI memory that is a warranty for safety and automatic recording of your measurements. Options such as data preview, copying and archiving are available to users as well.
The ALIBI memory allows to record up to 500 000 weighment records.

Under-Pan Weighing
Weighing instruments purchased after 15th February 2023 will allow under-pan weighing at any time after the purchase. All you need to do is just to order a dedicated hook.

THBR 2.0 System
Cooperation with THBR 2.0 System for ambient conditions monitoring.

Functions
• Autotest
• Dosing
• Percent Weighing
• Parts counting
• Peak hold
• Formulation
• Statistics
• Checkweighing
• IR sensors
• GLP Procedures
• Animal weighing
• Density determination
• Ambient conditions monitoring
• Replaceable unit
• Statistical Quality Control
• ALIBI Memory
• Mass for titrator
• Wi-Fi

Accessories
• Balance Storage Case
• Antivibration Tables
• Power Adapters
• RS 232 cables (scale - printer)
• Cigarette lighter receptacle power supply cables
• USB cable (scale - printer)
• Barcode scanners
• Under-pan weighing
• RS 232, RS 485 cables
• Density determination KIT
• Displays
• Receipt Printer
• RS 232, RS 485 cables
• Protective cover for balances
• Protective cover for balances
• RS 232 cables (scale - printer)
• RS 232 – RS 485 Converter

Software
• RAD-KEY
• Alibi Reader
• R-LAB
• Scales Editor 2.1
• RADWAG Development Studio

Model	WLC 0.2.X7 WL-227-0001	WLC 2.X7 WL-227-0005	WLC 6.X7 WL-227-0007	WLC 1/10.X7 WL-227-0009	WLC 10.X7 WL-227-0010	WLC 20.X7 WL-227-0011	WLC 21.X7 WL-227-0012
Capacity x Readability	200 g x 0.001 g	2000 g x 0.01 g	6000 g x 0.1 g	1000 g x 0.01 g 10 kg x 0.1 g	10 kg x 0.1 g	20 kg x 0.1 g	21 kg x 1 g
Tare range	-200 g	-2000 g	-6000 g	-10000 g	-10000 g	-20000 g	-21000 g
Linearity	+0.003 g	+0.03 g	+0.3 g	+0.03 g / +0.3 g	+0.3 g	+0.3 g	+3 g
Repeatability	0.0014 g	0.015 g	0.1 g	0.015 g / 0.08 g	0.08 g	0.1 g	0.8 g
Working temperature	+10 - +40 oC
Pan size	Ø 100 mm	195x195 mm
Stabilization time	2 s			4 / 2 s	3 s
Display	7 in graphic colour touchscreen
Delivery components	Balance, weighing pan, weighing pan shield, grounding bumper ×1, bumper ×3, power supply.
Power supply	Adapter: 100 – 240V AC 50/60Hz 0,6A; 12V DC 1,2A Balance: 10 – 15VDC 0,6A max
Interface	2×RS232 , USB-A, USB-B,Ethernet, Wi-Fi
Adjustment / Calibration	internal			external
Leveling system	manual
IP rating	IP 43
Database	7 databases
Net weight/Gross weight	1.8 kg / 3.4 kg	2.2 kg / 3.8 kg
Operating temperature	+10 - +40 oC

Repeatability is expressed as a standard deviation from 10 weighing cycles. Stabilization time depends on the ambient conditions and the dynamics of weighing pan loading; specified for FAST profile. 1 Barcode scanners, available as weighing instrument accessory, communicate with the instrument via RS232 interface exclusively
