Cambridge MODEL 680 Ultra Low Profile Floor Scales CCI Scales
Authorized Dealer
Cambridge Scale Works Model 680 Series Ultra-Lo Profile Floor Scale are Live safety side rails for oversized loads and roll off protection have a Structural tubular steel design. Anti-skid diamond deck plate and Anti-skid leveling feet Its height is from 1.5 to 2.5 inches
Cambridge MODEL 660 Low Profile Floor Scales
Base Only Indicator Sold Separately
Legal For Trade

Specifications Chart

Quick Order Here

Cambridge Scale Works Model 680 Series Ultra-Lo Profile Floor Scale are Live safety side rails for oversized loads and roll off protection have a Structural tubular steel design. Anti-skid diamond deck plate and Anti-skid leveling feet Its height is from 1.5 to 2.5 inches MODEL 680 STANDARD FEATURES
  • Live safety side rails for oversized loads and roll off protection
  • Structural tubular steel design
  • Anti-skid diamond deck plate
  • Anti-skid leveling feet
  • 100% end loading capacity
  • 200% overload protection
  • 20? indicator cable
  • Four internally mounted NTEP certified 5000 division class III/IIIL water resistant environmentally protected load cells
  • Easy access leveling feet
  • Easy access junction board for corner adjusting
  • Shielded signal and load cell cables
  • Ultra-lo profile design for jack truck & cart weighing
  • Powder coated finish
  • One part in 5000 accuracy
Underside has structural tubular steel design. Load cell position allows live side rails. OPTIONS
  • Easy incline ramps
  • Bumper rail assembly
  • Harsh environment package
  • Remote stainless steel junction box
  • Smooth plate
  • Stainless steel load cells
  • "FM" load cells

Other Options - Please call (800) 832-0055 for more info

Remote Stainless Steel "J" Box Remote S.S. NEMA IV Junction Box with 10 F.T. Sealtite flexible condut with two straight connectors
Stainless Steel Load Cells. Stainless Steel leveling feet. Stainless Steel hardware.
Stainless Steel hermetically sealed load cells. Stainless Steel leveling feet. Stainless Steel hardware.
"FM" Approved load cells. "FM" Approved load cells.
Cambridge MODEL 660 Ultra-Lo Profile Floor Scales

Price From: $1408.50



Select Indicator (Must be added with scale)
Cambridge (CSW-10AT) NTEP , Add $292.50
Cambridge (CSW-10AT-B) NTEP Battery Operated , Add $445.50
Cambridge (SSCSW-10AT) NTEP Stainless Steel , Add $535.50
Cambridge (SSCSW-10AT-B) NTEP Stainless Steel & Battery , Add $670.50
Cambridge (CSW-15AT) NTEP Wireless , Add $895.50
Cambridge (CSW-15AT-B) NTEP Wireless & Battery , Add $1035.00
Cambridge (CSW-20AT) NTEP Numeric Keypad , Add $598.50
Cambridge (CSW-20AT-B) NTEP Numeric Keypad & Battery , Add $742.50
Cambridge (SSCSW-20AT) NTEP Stainless Steel Numeric Keypad , Add $787.50
Cambridge (SSCSW-20AT-B) NTEPStainless Steel Numeric Keypad & Battery , Add $895.50

Options Must be added with scale

(Some Factory Installed)

Indicator Column\Stand
Cambridge - Attached  Indicator Column with Indicator Mounting Plate
Cambridge - Attached Indicator Column with Indicator Mounting Plate, add $247.50
Cambridge Stainless Steel 48 inch Rigid Free Standing Indictor Stand
Cambridge Stainless Steel 48 inch Rigid Free Standing Indictor Stand , add $607.50
Ramps
Cambridge RAM68036182 Model 680 Series Ramp 36 x 18 x 1.5
Cambridge RAM68036182 Model 680 Series Ramp 36 x 18 x 1.5, add $292.00
Cambridge RAM68048245 Model 680 Series Ramp 48 x 24 x 2
Cambridge RAM68048245 Model 680 Series Ramp 48 x 24 x 2, add $375.00
Cambridge RAM68048241 Model 680 Series Ramp 48 x 24 x 2
Cambridge RAM68048241 Model 680 Series Ramp 48 x 24 x 2, add $417.00
Cambridge RAM68060305 Model 680 Series Ramp 60 x 30 x 2.5
Cambridge RAM68060305 Model 680 Series Ramp 60 x 30 x 2.5, add $450.00
Cambridge RAM68060301 Model 680 Series Ramp 60 x 30 x 2.5
Cambridge RAM68060301 Model 680 Series Ramp 60 x 30 x 2.5, add $485.00

4 Side Bumper Guard
Cambridge 680BUM30 Model 680 Series Bumper Rail Assembly 30 Inches
Cambridge 680BUM30 Model 680 Series Bumper Rail Assembly 30 Inches, add $85.00
Cambridge 680BUM36  Model 680 Series  Bumper Rail Assembly 36 Inches
Cambridge 680BUM36 Model 680 Series Bumper Rail Assembly 36 Inches, add $92.00
Cambridge 680BUM48 Model 680 Series Bumper Rail Assembly 48 Inches
Cambridge 680BUM48 Model 680 Series Bumper Rail Assembly 48 Inches, add $110.00
Cambridge 680BUM60 Model 680 Series Bumper Rail Assembly 60 Inches
Cambridge 680BUM60 Model 680 Series Bumper Rail Assembly 60 Inches, add $120.00

Cambridge Scale MODEL 680 Series Ultra-Low Profile Floor Scales

Model Pan Size (Inch) Capacity x Readability Legal For Trade Price Base Only Price with CSW-10AT Indicator Overall Size (Inch)
680UL30301 30 x 30 x 1.5 1,000 x 0.1 lb NO - $1,408.50
$1,701.00
36 x 30
680UL30302 30 x 30 x 1.5 2,500 x 0.5 lb NO - $1,408.50
$1,701.00
36 x 30
680UL36361 36 x 36 x 1.5 1,000 x 0.1 lb NO - $1,458.00
$1,750.50
42 x 36
680UL36362 36 x 36 x 1.5 2,500 x 0.5 lb NO - $1,458.00
$1,750.50
42 x 36
680UL36481 36 x 48 x 1.5 1,000 x 0.1 lb NO - $1,494.00
$1,786.50
42 x 48
680UL36482 36 x 48 x 1.5 2,500 x 0.5 lb NO - $1,494.00
$1,786.50
42 x 48
680UL48485 48 x 48 x 2 5,000 x 0.5 lb YES 5,000 x 1 lb $1,557.00
$1,849.50
54 x 48
680UL48481 48 x 48 x 2 10,000 x 1 lb YES 10,000 x 2 lb $1,845.00
$2,137.50
54 x 48
680UL48605 48 x 60 x 2 5,000 x 0.5 lb YES 5,000 x 1 lb $1,701.00
$1,993.50
54 x 60
3860-1013-00 48 x 60 x 2 10,000 x 1 lb YES 10,000 x 2 lb $1,845.00
$2,137.50
54 x 60
680UL48725 48 x 72 x 2 5,000 x 0.5 lb YES 5,000 x 1 lb $1,845.00
$2,137.50
54 x 72
680UL48721 48 x 72 x 2 10,000 x 1 lb YES 10,000 x 2 lb $1,993.50
$2,286.00
54 x 72
680UL60605 60 x 60 x 2.5 5,000 x 0.5 lb YES 5,000 x 1 lb $1,944.00
$2,236.50
66 x 60
680UL60601 60 x 60 x 2.5 10,000 x 1 lb YES 10,000 x 2 lb $2,187.00
$2,479.50
66 x 60
680UL60725 60 x 72 x 2.5 5,000 x 0.5 lb YES 5,000 x 1 lb $2,187.00
$2,479.50
66 x 72
680UL60601 60 x 72 x 2.5 10,000 x 1 lb YES 10,000 x 2 lb $2,430.00
$2,722.50
66 x 72
680UL60845 60 x 84 x 2.5 5,000 x 0.5 lb YES 5,000 x 1 lb $2,430.00
$2,722.50
66 x 84
680UL60841 60 x 84 x 2.5 10,000 x 1 lb YES 10,000 x 2 lb $2,673.00
$2,668.95
66 x 84
