Cambridge MODEL 670-1 Barrel Scales with Built In Single Ramp Cambridge Scales
Authorized Dealer
Constructed of structural tubular steel and heavy gauge anti-skid diamond plate decking these scales are designed to handle the toughest applications. Incorporating all of the accuracy, reliability and strength you have come to expect from Cambridge Scale Works and backed by our one year warranty.
Cambridge 670130301 Model 670-1 Series Legal For Trade Weigher Scale Built In Single Ramp 30 x 30 x 1.5 / 1000 x 0.2
Base Only Indicator Sold Separately
Legal For Trade

Specifications Chart

Cambridge Model 670-1 Series Barrel Weigher Scale

Constructed of structural tubular steel and heavy gauge anti-skid diamond plate decking these scales are designed to handle the toughest applications. Incorporating all of the accuracy, reliability and strength you have come to expect from Cambridge Scale Works and backed by our one year warranty.

STANDARD FEATURES

  • Structural tubular steel construction.
  • Anti-skid diamond plate deck.
  • 100% End loading capacity.
  • 150% Overload protection.
  • 20 Foot indicator cable.
  • Eye bolt holes allow easy set-up.
  • Shielded load cell and indicator cables.
  • Ultra-low profile (1.5? above the floor).
  • Live side rails to weigh oversized loads.
  • 1 Part in 5000 accuracy.
  • Live built-in easy incline ramps.
  • Shock load protection.
  • (4) Internally mounted, Environmentally protected, NTEP certified-5000 Division, Class III/IIIL, IP 67 water resistant rated shear beam load cells.
  • Easy access leveling.

OPTIONS

  • Smooth carbon steel deck plate.
  • Remote NEMA 4x junction box with 10 Sealtite flexible conduit (available in stainless steel, plastic and ?FM? approved).
  • Load cell options: Stainless steel , Hermetically sealed S.S. , Teflon cables,?FM? approved
  • High Resolution Package Includes: Captive ball leveling feet for unmatched stability.
  • H.E.P. Package Includes: Stainless steel NEMA 4x J -box, Capped and sealed tubes, Stainless steel load cells, leveling feet and hardware, Sandblasted surface Cold zinc epoxy coating with urethane enamel finish coat
Cambridge MODEL 670-1 Barrel Scales with Built In Single Ramp

Price From: $3780.00



Select Indicator (Must be added with scale)
Cambridge (SSCSW-10AT) NTEP Stainless Steel , Add $535.50
Cambridge (SSCSW-10AT-B) NTEP Stainless Steel & Battery , Add $670.50
Cambridge (CSW-15AT) NTEP Wireless , Add $895.50
Cambridge (CSW-15AT-B) NTEP Wireless & Battery , Add $1035.00
Cambridge (CSW-20AT) NTEP Numeric Keypad , Add $598.50
Cambridge (CSW-20AT-B) NTEP Numeric Keypad & Battery , Add $742.50
Cambridge (SSCSW-20AT) NTEP Stainless Steel Numeric Keypad , Add $787.50
Cambridge (SSCSW-20AT-B) NTEPStainless Steel Numeric Keypad & Battery , Add $895.50

Options Must be added with scale

(Some Factory Installed)

Indicator Column\Stand
Cambridge -50481 Attached Stainless-Steel Indicator 48 inch  Column with Indicator Mounting Plate
Cambridge -50481 Attached Stainless-Steel Indicator 48 inch Column with Indicator Mounting Plate, add $697.50

Other Options - Please call (800) 832-0055 for more info

Remote Stainless Steel "J" Box Remote S.S. NEMA IV Junction Box with 10 F.T. Sealtite flexible condut with two straight connectors
Cambridge Model 670-1 Series Barrel Weigher Scale
Model S670130301 S670130302 S670130305 S670136361 S670136362 S670136365
Cambridge S670130301 Mode
$3,780.00
Cambridge S670130302 Mode
$3,780.00
Cambridge S670130305 Mode
$3,870.00
Cambridge S670136361 Mode
$3,996.00
Cambridge S670136362 Mode
$3,996.00
Cambridge S670136365 Mode
$4,104.00
Capacity 1,000 x 0.2 lb 2,500 x 0.5 lb 5,000 x 1 lb 1,000 x 0.2 lb 2,500 x 0.5 lb 5,000 x 1 lb
Platform Size 30" x 30" x 1.5" 30" x 30" x 1.5" 30" x 30 x 1.5" 36" x 36" x 1.5" 36" x 36" x 1.5" 36" x 36" x 1.5"
Model With Indicator S670130301K S670130302K S670130305K S670136361K S670136362K S670136365K
Cambridge S670130301K Mod
$4,072.50
Cambridge S670130302K Mod
$4,072.50
Cambridge S670130305K Mod
$4,162.50
Cambridge S670136361K Mod
$4,288.50
Cambridge S670136362K Mod
$4,288.50
Cambridge S670136365K Mod
$4,396.50
Legal For Trade NTEP certified-5000 Division, Class III/IIIL,
Overload protection 150%
Indicator Cable 20 Foot
Rated IP 67 water resistant
Plate Deck Anti-skid diamond
Accuracy 1 Part in 5000
dims
